Application of slip ring in high speed ball?
Cap slip ring, as the name implies, is the shape of a hat like slip ring. Cap type slip ring outer flannel, mainly through several fixed holes on the flannel to cooperate with the customer's equipment installation, so the cap type slip ring is generally fixed in the outer layer, a structure of inner axis rotation.
The characteristics of the stator insulation base are: Include at least two rotor and rotor insulation cover plate gang electric circle, at least two relatively static stator and stator insulation base electrode, at least two conductive ring, for at least two rotor stator and at least two stator insulation base electrode least two groups of brush, ball every conductive ring rotor and stator electric circle concentric assembly respectively in the stator and rotor insulation cover between insulating base, At least one set of ball brushes are rolled between each rotor conducting ring and the matched stator conducting ring. Each stator electrode is connected with the corresponding rotor conductive ring through the rotor insulation cover plate, and each stator electrode is connected with the corresponding stator conductive ring through the stator rotor insulation base.
