The circular path of the cylindrical slip ring is arranged along the axis of the cylinder, and the circular path of the disc slip ring is a concentric circle. The contact resistance is affected by the pressure, material and contact form between the slip ring and the brush wire. It is an important part of the conductive slip ring, and has the advantages of large number of brush wires, fine brush wires, and small spacing. The pressure of the brush wire on the slip ring will directly affect the contact resistance, the greater the pressure, the smaller the contact resistance.
The parameters of the conductive slip ring can better reflect the performance of the conductive slip ring, and the problems can be found and solved immediately. The working principle of the Electric Slip Ring is to transmit high-definition signal, control and current from the stationary device of the slip ring to the 360° conductive device of the rotating device. It is especially suitable for small and medium-sized weak control signal equipment such as high-speed ball heads.
